Humanitec Integration

This guide demonstrates how to create a GitHub worklow integration to facilitate the ingestion of Humanitec applications, environments, workloads, resources, resource graphs, pipelines, deployment deltas, deployment sets, secret stores, shared values, value set versions, users, groups into your Port catalog on schedule.

Common use cases

• Empower platform teams to gain visibility and advanced insights into your Humanitec entities including application, environments, users, and groups from Port among other entities.
• Track the status of changes to your Humanitec entities from Port.
• Prepare your Port environment to build useful experiences for Platform Engineering teams with Self Service Actions.

Prerequisites

This guide assumes the following:

• You have a Port account and have completed the onboarding process.
• You have a Humanitec account and a Service User created (You need an Administrator or Manager privilege to create a Service User).
• You have a GitHub account and a repository.

Set up data model

As a first step, you need to create blueprint definitions in Port for the Humanitec entities you want to ingest. To do this follow the steps below:

1. Go to the Builder page in your Port organization.
2. Click on the + Blueprint button at the top of the page.
3. Click on {...} Edit JSON button at the top right corner.
4. Copy and paste the following blueprint JSON into the editor, repeating the process for each blueprint:

Humanitec Application Blueprint (Click to expand)

{
  "identifier": "humanitecApplication",
  "description": "Humanitec Application",
  "title": "humanitecApplication",
  "icon": "Apps",
  "schema": {
    "properties": {
      "createdAt": {
        "type": "string",
        "title": "Created At",
        "format": "date-time"
      }
    },
    "required": []
  },
  "mirrorProperties": {},
  "calculationProperties": {},
  "aggregationProperties": {},
  "relations": {}
}

Humanitec Environment Blueprint (Click to expand)

{
  "identifier": "humanitecEnvironment",
  "title": "Humanitec Environment",
  "icon": "Environment",
  "schema": {
    "properties": {
      "type": {
        "title": "Type",
        "icon": "DefaultProperty",
        "type": "string"
      },
      "createdAt": {
        "type": "string",
        "format": "date-time",
        "title": "Creation Date",
        "description": "The date and time when the environment was created."
      },
      "lastDeploymentStatus": {
        "type": "string",
        "title": "Last Deployment Status",
        "description": "The status of the last deployment."
      },
      "lastDeploymentDate": {
        "type": "string",
        "format": "date-time",
        "title": "Last Deployment Date",
        "description": "The date and time of the last time the environment was deployed."
      },
      "lastDeploymentComment": {
        "type": "string",
        "title": "Last Deployment Comment",
        "description": "comment on the last deployment"
      }
    },
    "required": []
  },
  "mirrorProperties": {},
  "calculationProperties": {},
  "aggregationProperties": {},
  "relations": {
    "humanitecApplication": {
      "title": "Application",
      "target": "humanitecApplication",
      "required": false,
      "many": false
    }
  }
}

Humanitec Workload Blueprint (Click to expand)

{
  "identifier": "humanitecWorkload",
  "title": "Workload",
  "icon": "Cluster",
  "schema": {
    "properties": {
      "class": {
        "title": "Class",
        "description": "The class of the workload",
        "type": "string",
        "icon": "DefaultProperty"
      },
      "driverType": {
        "title": "Driver Type",
        "description": "The driver type of the workload",
        "type": "string",
        "icon": "DefaultProperty"
      },
      "definitionId": {
        "title": "Definition ID",
        "description": "The definition ID of the workload",
        "type": "string",
        "icon": "DefaultProperty"
      },
      "definitionVersionId": {
        "title": "Definition Version ID",
        "description": "The definition version ID of the workload",
        "type": "string",
        "icon": "DefaultProperty"
      },
      "status": {
        "title": "Status",
        "description": "The status of the workload",
        "type": "string",
        "icon": "DefaultProperty"
      },
      "updatedAt": {
        "title": "Update Date",
        "description": "The date and time when the workload was last updated",
        "type": "string",
        "format": "date-time",
        "icon": "DefaultProperty"
      }
    },
    "required": []
  },
  "mirrorProperties": {},
  "calculationProperties": {},
  "aggregationProperties": {},
  "relations": {
    "humanitecEnvironment": {
      "title": "Environment",
      "target": "humanitecEnvironment",
      "required": false,
      "many": false
    }
  }
}

Humanitec Resource Graph Blueprint (Click to expand)

{
  "identifier": "humanitecResourceGraph",
  "description": "Humanitec Resource Graph",
  "title": "Resource Graph",
  "icon": "Microservice",
  "schema": {
    "properties": {},
    "required": []
  },
  "mirrorProperties": {},
  "calculationProperties": {},
  "aggregationProperties": {},
  "relations": {
    "humanitecResourceGraph": {
      "title": "Resource Graph",
      "target": "humanitecResourceGraph",
      "required": false,
      "many": true
    }
  }
}

Humanitec Resource Blueprint (Click to expand)

{
  "identifier": "humanitecResource",
  "title": "Humanitec Resource",
  "icon": "Microservice",
  "schema": {
    "properties": {
      "type": {
        "title": "Type",
        "description": "The type of the resource",
        "type": "string",
        "icon": "DefaultProperty"
      },
      "class": {
        "title": "Class",
        "description": "The class of the resource",
        "type": "string",
        "icon": "DefaultProperty"
      },
      "resource": {
        "title": "Resource",
        "description": "The resource",
        "type": "object",
        "icon": "DefaultProperty"
      },
      "resourceSchema": {
        "title": "Resource Schema",
        "description": "The schema of the resource",
        "type": "object",
        "icon": "DefaultProperty"
      },
      "guresid": {
        "title": "GU Resource ID",
        "description": "The GU resource ID",
        "type": "string",
        "icon": "DefaultProperty"
      }
    },
    "required": []
  },
  "mirrorProperties": {},
  "calculationProperties": {},
  "aggregationProperties": {},
  "relations": {
    "humanitecResourceGraph": {
      "title": "Depends On",
      "description": "Resource Graph",
      "target": "humanitecResourceGraph",
      "required": false,
      "many": true
    },
    "humanitecWorkload": {
      "title": "Humanitec Workload",
      "target": "humanitecWorkload",
      "required": false,
      "many": false
    }
  }
}

Humanitec Secret Stores (Click to expand)

{
    "identifier": "humanitecSecretStore",
    "title": "Humanitec Secret Store",
    "icon": "Lock",
    "schema": {
      "properties": {
        "primary": {
          "title": "Primary",
          "description": "Whether this is the primary secret store",
          "type": "boolean",
          "icon": "DefaultProperty"
        },
        "createdAt": {
          "title": "Created At",
          "description": "The date and time when the secret store was created",
          "type": "string",
          "format": "date-time",
          "icon": "DefaultProperty"
        },
        "createdBy": {
          "title": "Created By",
          "description": "The user who created the secret store",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "updatedAt": {
          "title": "Updated At",
          "description": "The date and time when the secret store was last updated",
          "type": "string",
          "format": "date-time",
          "icon": "DefaultProperty"
        },
        "updatedBy": {
          "title": "Updated By",
          "description": "The user who last updated the secret store",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "awssm": {
          "title": "AWS Secrets Manager",
          "description": "AWS Secrets Manager configuration",
          "type": "object",
          "icon": "DefaultProperty"
        },
        "azurekv": {
          "title": "Azure Key Vault",
          "description": "Azure Key Vault configuration",
          "type": "object",
          "icon": "DefaultProperty"
        },
        "gcpsm": {
          "title": "Google Cloud Secret Manager",
          "description": "Google Cloud Secret Manager configuration",
          "type": "object",
          "icon": "DefaultProperty"
        },
        "humanitec": {
          "title": "Humanitec",
          "description": "Humanitec secret store configuration",
          "type": "object",
          "icon": "DefaultProperty"
        },
        "vault": {
          "title": "Vault",
          "description": "HashiCorp Vault configuration",
          "type": "object",
          "icon": "DefaultProperty"
        }
      },
      "required": []
    },
    "mirrorProperties": {},
    "calculationProperties": {},
    "aggregationProperties": {},
    "relations": {}
}

Humanitec Shared Values (Click to expand)

{
    "identifier": "humanitecSharedValue",
    "title": "Humanitec Shared Value",
    "icon": "Settings",
    "schema": {
      "properties": {
        "description": {
          "title": "Description",
          "description": "A human friendly description of what the Shared Value is",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "isSecret": {
          "title": "Is Secret",
          "description": "Specified that the Shared Value contains a secret",
          "type": "boolean",
          "icon": "DefaultProperty"
        },
        "secretKey": {
          "title": "Secret Key",
          "description": "Location of the secret value in the secret store",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "secretVersion": {
          "title": "Secret Version",
          "description": "Version of the current secret value as returned by the secret store",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "source": {
          "title": "Source",
          "description": "Source of the value, 'app' for app level, 'env' for app env level",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "value": {
          "title": "Value",
          "description": "The value that will be stored (will be always empty for secrets)",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "createdAt": {
          "title": "Created At",
          "description": "The date and time when the shared value was created",
          "type": "string",
          "format": "date-time",
          "icon": "DefaultProperty"
        },
        "updatedAt": {
          "title": "Updated At",
          "description": "The date and time when the shared value was last updated",
          "type": "string",
          "format": "date-time",
          "icon": "DefaultProperty"
        }
      },
      "required": []
    },
    "mirrorProperties": {},
    "calculationProperties": {},
    "aggregationProperties": {},
    "relations": {
      "humanitecApplication": {
        "title": "Application",
        "target": "humanitecApplication",
        "required": false,
        "many": false
      },
      "humanitecEnvironment": {
        "title": "Environment",
        "target": "humanitecEnvironment",
        "required": false,
        "many": false
      },
      "humanitecSecretStore": {
        "title": "Secret Store",
        "target": "humanitecSecretStore",
        "required": false,
        "many": false
      }
    }
}

Humanitec Value Set Versions (Click to expand)

{
    "identifier": "humanitecValueSetVersion",
    "title": "Humanitec Value Set Version",
    "icon": "Version",
    "schema": {
      "properties": {
        "version": {
          "title": "Version",
          "description": "The version number",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "createdAt": {
          "title": "Created At",
          "description": "The date and time when the value set version was created",
          "type": "string",
          "format": "date-time",
          "icon": "DefaultProperty"
        },
        "createdBy": {
          "title": "Created By",
          "description": "The user who created the value set version",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "comment": {
          "title": "Comment",
          "description": "Comment for the value set version",
          "type": "string",
          "icon": "DefaultProperty"
        }
      },
      "required": []
    },
    "mirrorProperties": {},
    "calculationProperties": {},
    "aggregationProperties": {},
    "relations": {
      "humanitecApplication": {
        "title": "Application",
        "target": "humanitecApplication",
        "required": false,
        "many": false
      }
    }
}

Humanitec Deployment Sets (Click to expand)

{
    "identifier": "humanitecDeploymentSet",
    "title": "Humanitec Deployment Set",
    "icon": "Deployment",
    "schema": {
      "properties": {
        "version": {
          "title": "Version",
          "description": "The version of the deployment set",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "createdAt": {
          "title": "Created At",
          "description": "The date and time when the deployment set was created",
          "type": "string",
          "format": "date-time",
          "icon": "DefaultProperty"
        },
        "createdBy": {
          "title": "Created By",
          "description": "The user who created the deployment set",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "comment": {
          "title": "Comment",
          "description": "Comment for the deployment set",
          "type": "string",
          "icon": "DefaultProperty"
        }
      },
      "required": []
    },
    "mirrorProperties": {},
    "calculationProperties": {},
    "aggregationProperties": {},
    "relations": {
      "humanitecApplication": {
        "title": "Application",
        "target": "humanitecApplication",
        "required": false,
        "many": false
      }
    }
}

Humanitec Pipelines (Click to expand)

{
    "identifier": "humanitecPipeline",
    "title": "Humanitec Pipeline",
    "icon": "Pipeline",
    "schema": {
      "properties": {
        "etag": {
          "title": "ETag",
          "description": "Entity tag for the pipeline",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "name": {
          "title": "Name",
          "description": "The name of the pipeline",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "status": {
          "title": "Status",
          "description": "The status of the pipeline",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "version": {
          "title": "Version",
          "description": "The version of the pipeline",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "createdAt": {
          "title": "Created At",
          "description": "The date and time when the pipeline was created",
          "type": "string",
          "format": "date-time",
          "icon": "DefaultProperty"
        },
        "triggerTypes": {
          "title": "Trigger Types",
          "description": "Types of triggers for the pipeline",
          "type": "array",
          "icon": "DefaultProperty"
        },
        "metadata": {
          "title": "Metadata",
          "description": "Additional metadata for the pipeline",
          "type": "object",
          "icon": "DefaultProperty"
        }
      },
      "required": []
    },
    "mirrorProperties": {},
    "calculationProperties": {},
    "aggregationProperties": {},
    "relations": {
      "humanitecApplication": {
        "title": "Application",
        "target": "humanitecApplication",
        "required": false,
        "many": false
      }
    }
}

Humanitec Deployment Deltas (Click to expand)

{
    "identifier": "humanitecDeploymentDelta",
    "title": "Humanitec Deployment Delta",
    "icon": "Deployment",
    "schema": {
      "properties": {
        "status": {
          "title": "Status",
          "description": "The status of the deployment delta",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "createdAt": {
          "title": "Created At",
          "description": "The date and time when the deployment delta was created",
          "type": "string",
          "format": "date-time",
          "icon": "DefaultProperty"
        },
        "createdBy": {
          "title": "Created By",
          "description": "The user who created the deployment delta",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "comment": {
          "title": "Comment",
          "description": "Comment for the deployment delta",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "environment": {
          "title": "Environment",
          "description": "The environment for the deployment delta",
          "type": "string",
          "icon": "DefaultProperty"
        }
      },
      "required": []
    },
    "mirrorProperties": {},
    "calculationProperties": {},
    "aggregationProperties": {},
    "relations": {
      "humanitecApplication": {
        "title": "Application",
        "target": "humanitecApplication",
        "required": false,
        "many": false
      }
    }
}

Humanitec Users (Click to expand)

{
    "identifier": "humanitecUser",
    "title": "Humanitec User",
    "icon": "User",
    "schema": {
      "properties": {
        "email": {
          "title": "Email",
          "description": "The email address of the user",
          "type": "string",
          "icon": "User",
          "format": "user"
        },
        "role": {
          "title": "Role",
          "description": "The role of the user in the organization",
          "type": "string",
          "icon": "Role"
        },
        "invite": {
          "title": "Invite Status",
          "description": "The status of the user's invitation",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "createdAt": {
          "title": "Created At",
          "description": "The date and time when the user was created",
          "type": "string",
          "format": "date-time",
          "icon": "DefaultProperty"
        }
      },
      "required": []
    },
    "mirrorProperties": {},
    "calculationProperties": {},
    "aggregationProperties": {},
    "relations": {
      "humanitecGroup": {
        "title": "Groups",
        "target": "humanitecGroup",
        "required": false,
        "many": true
      }
    }
}

Humanitec Groups (Click to expand)

{
    "identifier": "humanitecGroup",
    "title": "Humanitec Group",
    "icon": "TwoUsers",
    "schema": {
      "properties": {
        "role": {
          "title": "Role",
          "description": "The role of the group in the organization",
          "type": "string",
          "icon": "Role"
        },
        "idp_id": {
          "title": "IDP ID",
          "description": "The identity provider ID",
          "type": "string",
          "icon": "DefaultProperty"
        },
        "createdAt": {
          "title": "Created At",
          "description": "The date and time when the group was created",
          "type": "string",
          "format": "date-time",
          "icon": "DefaultProperty"
        }
      },
      "required": []
    },
    "mirrorProperties": {},
    "calculationProperties": {},
    "aggregationProperties": {},
    "relations": {}
}

Blueprint Properties

You may select the blueprints depending on what you want to track in your Humanitec account.

Set up the integration

Fork our humanitec integration repository to get started.

Add secrets to your GitHub repository

In your GitHub repository, go to Settings > Secrets and add the following secrets:

• HUMANITEC_API_KEY - Humanitec API Key
• HUMANITEC_ORG_ID - Humanitec Organization ID
• PORT_CLIENT_ID - Your Port client id How to get the credentials.
• PORT_CLIENT_SECRET - Your Port client secret How to get the credentials.

Create the Python files

1. Create the following Python files in a folder named integration at the base directory of your GitHub repository:

   • main.py - Orchestrates the synchronization of data from Humanitec to Port, ensuring that resource entities are accurately mirrored and updated on your Port catalog.
   • requirements.txt - This file contains the dependencies or necessary external packages need to run the integration
   Main Executable Script (Click to expand)

   main.py


   import asyncio
   import argparse
   import time
   import datetime
   from decouple import config  # type: ignore
   import re
   import asyncio
   from loguru import logger
   from clients.humanitec_client import HumanitecClient
   from clients.port_client import PortClient
   import httpx


   class BLUEPRINT:
       APPLICATION = "humanitecApplication"
       ENVIRONMENT = "humanitecEnvironment"
       WORKLOAD = "humanitecWorkload"
       RESOURCE_GRAPH = "humanitecResourceGraph"
       RESOURCE = "humanitecResource"
       SECRET_STORE = "humanitecSecretStore"
       SHARED_VALUE = "humanitecSharedValue"
       VALUE_SET_VERSION = "humanitecValueSetVersion"
       DEPLOYMENT_SET = "humanitecDeploymentSet"
       PIPELINE = "humanitecPipeline"
       DEPLOYMENT_DELTA = "humanitecDeploymentDelta"
       USER = "humanitecUser"
       GROUP = "humanitecGroup"


   class HumanitecExporter:
       def __init__(self, args) -> None:

           timeout = httpx.Timeout(10.0, connect=10.0, read=20.0, write=10.0)
           httpx_async_client = httpx.AsyncClient(timeout=timeout)
           self.port_client = PortClient(
               args.port_client_id,
               args.port_client_secret,
               httpx_async_client=httpx_async_client,
           )
           self.humanitec_client = HumanitecClient(
               args.org_id,
               args.api_key,
               api_url=args.api_url,
               httpx_async_client=httpx_async_client,
           )

       @staticmethod
       def convert_to_datetime(timestamp: int) -> str:
           converted_datetime = datetime.datetime.fromtimestamp(
               timestamp / 1000.0, datetime.timezone.utc
           )
           return converted_datetime.strftime("%Y-%m-%dT%H:%M:%SZ")

       @staticmethod
       def remove_symbols_and_title_case(input_string: str) -> str:
           cleaned_string = re.sub(r"[^A-Za-z0-9\s]", " ", input_string)
           title_case_string = cleaned_string.title()
           return title_case_string

       async def sync_applications(self) -> None:
           logger.info(f"Syncing entities for blueprint {BLUEPRINT.APPLICATION}")
           applications = await self.humanitec_client.get_all_applications()

           def create_entity(application):
               return {
                   "identifier": application["id"],
                   "title": self.remove_symbols_and_title_case(application["name"]),
                   "properties": {"createdAt": application["created_at"]},
                   "relations": {},
               }

           tasks = [
               self.port_client.upsert_entity(
                   blueprint_id=BLUEPRINT.APPLICATION,
                   entity_object=create_entity(application),
               )
               for application in applications
           ]

           await asyncio.gather(*tasks)
           logger.info(f"Finished syncing entities for blueprint {BLUEPRINT.APPLICATION}")

       async def sync_environments(self) -> None:
           logger.info(f"Syncing entities for blueprint {BLUEPRINT.ENVIRONMENT}")
           applications = await self.humanitec_client.get_all_applications()

           def create_entity(application, environment):
               return {
                   "identifier": f"{application['id']}/{environment['id']}",
                   "title": environment["name"],
                   "properties": {
                       "type": environment["type"],
                       "createdAt": environment["created_at"],
                       "lastDeploymentStatus": environment.get("last_deploy", {}).get(
                           "status"
                       ),
                       "lastDeploymentDate": environment.get("last_deploy", {}).get(
                           "created_at"
                       ),
                       "lastDeploymentComment": environment.get("last_deploy", {}).get(
                           "comment"
                       ),
                   },
                   "relations": {BLUEPRINT.APPLICATION: application["id"]},
               }

           tasks = [
               self.port_client.upsert_entity(
                   blueprint_id=BLUEPRINT.ENVIRONMENT,
                   entity_object=create_entity(application, environment),
               )
               for application in applications
               for environments in [
                   await self.humanitec_client.get_all_environments(application)
               ]
               for environment in environments
           ]
           await asyncio.gather(*tasks)
           logger.info(f"Finished syncing entities for blueprint {BLUEPRINT.ENVIRONMENT}")

       async def sync_workloads(self):
           logger.info(f"Syncing entities for blueprint {BLUEPRINT.WORKLOAD}")

           def create_workload_entity(resource, application, environment):
               identifier = f"{application['id']}/{environment['id']}/{resource['res_id'].replace('modules.', '')}"
               return {
                   "identifier": identifier,
                   "title": self.remove_symbols_and_title_case(
                       resource["res_id"].replace("modules.", "")
                   ),
                   "properties": {
                       "status": resource["status"],
                       "class": resource["class"],
                       "driverType": resource["driver_type"],
                       "definitionVersionId": resource["def_version_id"],
                       "definitionId": resource["def_id"],
                       "updatedAt": resource["updated_at"],
                       "graphResourceID": resource["gu_res_id"],
                   },
                   "relations": {
                       BLUEPRINT.ENVIRONMENT: f"{application['id']}/{environment['id']}",
                   },
               }

           applications = await self.humanitec_client.get_all_applications()
           for application in applications:
               environments = await self.humanitec_client.get_all_environments(application)
               for environment in environments:
                   resources = await self.humanitec_client.get_all_resources(
                       application, environment
                   )
                   resource_group = self.humanitec_client.group_resources_by_type(
                       resources
                   )
                   tasks = [
                       self.port_client.upsert_entity(
                           blueprint_id=BLUEPRINT.WORKLOAD,
                           entity_object=create_workload_entity(resource, application, environment),
                       )
                       for resource in resource_group.get("modules", [])
                       if resource and resource["type"] == "workload"
                   ]
                   await asyncio.gather(*tasks)
           logger.info(f"Finished syncing entities for blueprint {BLUEPRINT.WORKLOAD}")

       async def sync_resource_graphs(self) -> None:
           logger.info(f"Syncing entities for blueprint {BLUEPRINT.RESOURCE_GRAPH}")

           def create_resource_graph_entity(
               graph_data, include_relations, application, environment
           ):
               entity = {
                   "identifier": graph_data["guresid"],
                   "title": self.remove_symbols_and_title_case(graph_data["def_id"]),
                   "properties": {
                       "type": graph_data["type"],
                       "class": graph_data["class"],
                       "resourceSchema": graph_data["resource_schema"],
                       "resource": graph_data["resource"],
                   },
                   "relations": {},
               }
               if include_relations:

                   entity["relations"] = {
                       BLUEPRINT.RESOURCE_GRAPH: graph_data["depends_on"],
                       BLUEPRINT.ENVIRONMENT: f"{application['id']}/{environment['id']}",
                   }
               return entity

           applications = await self.humanitec_client.get_all_applications()
           for application in applications:
               environments = await self.humanitec_client.get_all_environments(application)
               for environment in environments:
                   graph_nodes = await self.humanitec_client.get_dependency_graph(
                       application, environment
                   )

                   # First pass: Create entities without relations
                   tasks = [
                       self.port_client.upsert_entity(
                           blueprint_id=BLUEPRINT.RESOURCE_GRAPH,
                           entity_object=create_resource_graph_entity(
                               node, False, application, environment
                           ),
                       )
                       for node in graph_nodes
                   ]
                   await asyncio.gather(*tasks)

                   # Second pass: Update entities with relations
                   tasks = [
                       self.port_client.upsert_entity(
                           blueprint_id=BLUEPRINT.RESOURCE_GRAPH,
                           entity_object=create_resource_graph_entity(
                               node, True, application, environment
                           ),
                       )
                       for node in graph_nodes
                   ]
                   await asyncio.gather(*tasks)
           logger.info(
               f"Finished syncing entities for blueprint {BLUEPRINT.RESOURCE_GRAPH}"
           )

       async def enrich_resource_with_graph(self, resource, application, environment):
           try:
               logger.info("Enriching resource %s with graph", resource["res_id"])
               data = {
                   "id": resource["res_id"],
                   "type": resource["type"],
                   "resource": resource["resource"],
               }
               response = await self.humanitec_client.get_resource_graph(
                   application, environment, [data]
               )

               resource.update(
                   {"__resourceGraph": i for i in response if i["type"] == data["type"]}
               )
               return resource
           except Exception as e:
               logger.error(
                   f"Failed to enrich resource {resource['res_id']} with graph: %s", str(e)
               )
               return resource

       async def sync_resources(self) -> None:
           logger.info(f"Syncing entities for blueprint {BLUEPRINT.RESOURCE}")

           def create_resource_entity(resource):
               workload_id = (
                   resource["res_id"].split(".")[1]
                   if resource["res_id"].split(".")[0].startswith("modules")
                   else ""
               )
               resource_id = (
                   f"{resource['app_id']}/{resource['env_id']}/{resource['res_id']}"
               )
               entity = {
                   "identifier": resource_id,
                   "title": self.remove_symbols_and_title_case(resource["def_id"]),
                   "properties": {
                       "type": resource["type"],
                       "class": resource["class"],
                       "resource": resource["resource"],
                       "status": resource["status"],
                       "updateAt": resource["updated_at"],
                       "driverType": resource["driver_type"],
                   },
                   "relations": {},
               }
               if workload_id:
                   workload_id = f"{resource['app_id']}/{resource['env_id']}/{workload_id}"
                   entity["relations"][BLUEPRINT.WORKLOAD] = workload_id
               return entity

           applications = await self.humanitec_client.get_all_applications()
           for application in applications:
               environments = await self.humanitec_client.get_all_environments(application)
               for environment in environments:
                   resources = await self.humanitec_client.get_all_resources(
                       application, environment
                   )

                   entity_tasks = [
                       self.port_client.upsert_entity(
                           blueprint_id=BLUEPRINT.RESOURCE,
                           entity_object=create_resource_entity(resource),
                       )
                       for resource in resources
                   ]
                   await asyncio.gather(*entity_tasks)
                   logger.info(
                       "Upserted resource entities for %s environment", environment["id"]
                   )

           logger.info(f"Finished syncing entities for blueprint {BLUEPRINT.RESOURCE}")

       async def sync_secret_stores(self) -> None:
           logger.info(f"Syncing entities for blueprint {BLUEPRINT.SECRET_STORE}")
           secret_stores = await self.humanitec_client.get_secret_stores()

           def create_secret_store_entity(secret_store):
               # Determine the secret store type based on which configuration is present
               secret_store_type = "unknown"
               if secret_store.get("awssm") is not None:
                   secret_store_type = "AWS Secrets Manager"
               elif secret_store.get("azurekv") is not None:
                   secret_store_type = "Azure Key Vault"
               elif secret_store.get("gcpsm") is not None:
                   secret_store_type = "Google Cloud Secret Manager"
               elif secret_store.get("humanitec") is not None:
                   secret_store_type = "Humanitec"
               elif secret_store.get("vault") is not None:
                   secret_store_type = "HashiCorp Vault"

               # Create a title based on the type and ID
               title = f"{secret_store_type} - {secret_store['id']}"
               if secret_store.get("primary"):
                   title = f"{title} (Primary)"

               return {
                   "identifier": secret_store["id"],
                   "title": title,
                   "properties": {
                       "primary": secret_store.get("primary", False),
                       "createdAt": secret_store.get("created_at"),
                       "createdBy": secret_store.get("created_by"),
                       "updatedAt": secret_store.get("updated_at"),
                       "updatedBy": secret_store.get("updated_by"),
                       "awssm": secret_store.get("awssm"),
                       "azurekv": secret_store.get("azurekv"),
                       "gcpsm": secret_store.get("gcpsm"),
                       "humanitec": secret_store.get("humanitec"),
                       "vault": secret_store.get("vault"),
                   },
                   "relations": {},
               }

           tasks = [
               self.port_client.upsert_entity(
                   blueprint_id=BLUEPRINT.SECRET_STORE,
                   entity_object=create_secret_store_entity(secret_store),
               )
               for secret_store in secret_stores
           ]

           await asyncio.gather(*tasks)
           logger.info(f"Finished syncing entities for blueprint {BLUEPRINT.SECRET_STORE}")

       async def sync_shared_values(self) -> None:
           logger.info(f"Syncing entities for blueprint {BLUEPRINT.SHARED_VALUE}")
           applications = await self.humanitec_client.get_all_applications()

           def create_shared_value_entity(shared_value, application, environment=None):
               # Create identifier based on source and context
               if environment:
                   identifier = f"{application['id']}/{environment['id']}/{shared_value['key']}"
               else:
                   identifier = f"{application['id']}/{shared_value['key']}"


               # Build relations
               relations = {BLUEPRINT.APPLICATION: application["id"]}

               if environment:
                   relations[BLUEPRINT.ENVIRONMENT] = f"{application['id']}/{environment['id']}"

               # Add secret store relation if present
               if shared_value.get("secret_store_id"):
                   relations[BLUEPRINT.SECRET_STORE] = shared_value["secret_store_id"]

               return {
                   "identifier": identifier,
                   "title": shared_value["key"],
                   "properties": {
                       "description": shared_value.get("description"),
                       "isSecret": shared_value.get("is_secret", False),
                       "key": shared_value.get("key"),
                       "secretKey": shared_value.get("secret_key"),
                       "secretVersion": shared_value.get("secret_version"),
                       "source": shared_value.get("source"),
                       "value": shared_value.get("value"),
                       "createdAt": shared_value.get("created_at"),
                       "updatedAt": shared_value.get("updated_at"),
                   },
                   "relations": relations,
               }

           # Sync app-level shared values
           app_level_tasks = []
           for application in applications:
               shared_values = await self.humanitec_client.get_shared_values_app_level(application)
               app_level_tasks.extend([
                   self.port_client.upsert_entity(
                       blueprint_id=BLUEPRINT.SHARED_VALUE,
                       entity_object=create_shared_value_entity(shared_value, application),
                   )
                   for shared_value in shared_values
               ])

           # Sync environment-level shared values
           env_level_tasks = []
           for application in applications:
               environments = await self.humanitec_client.get_all_environments(application)
               for environment in environments:
                   shared_values = await self.humanitec_client.get_shared_values(application, environment)
                   env_level_tasks.extend([
                       self.port_client.upsert_entity(
                           blueprint_id=BLUEPRINT.SHARED_VALUE,
                           entity_object=create_shared_value_entity(shared_value, application, environment),
                       )
                       for shared_value in shared_values
                   ])

           await asyncio.gather(*(app_level_tasks + env_level_tasks))
           logger.info(f"Finished syncing entities for blueprint {BLUEPRINT.SHARED_VALUE}")

       async def sync_value_set_versions(self) -> None:
           logger.info(f"Syncing entities for blueprint {BLUEPRINT.VALUE_SET_VERSION}")
           applications = await self.humanitec_client.get_all_applications()

           def create_value_set_version_entity(value_set_version, application):
               return {
                   "identifier": f"{application['id']}/{value_set_version['id']}",
                   "title": f"Value Set Version {value_set_version['id']}",
                   "properties": {
                       "version": value_set_version.get("version"),
                       "createdAt": value_set_version.get("created_at"),
                       "createdBy": value_set_version.get("created_by"),
                       "comment": value_set_version.get("comment"),
                   },
                   "relations": {BLUEPRINT.APPLICATION: application["id"]},
               }

           tasks = []
           for application in applications:
               value_set_versions = await self.humanitec_client.get_value_set_versions(application)
               tasks.extend([
                   self.port_client.upsert_entity(
                       blueprint_id=BLUEPRINT.VALUE_SET_VERSION,
                       entity_object=create_value_set_version_entity(value_set_version, application),
                   )
                   for value_set_version in value_set_versions
               ])

           await asyncio.gather(*tasks)
           logger.info(f"Finished syncing entities for blueprint {BLUEPRINT.VALUE_SET_VERSION}")

       async def sync_deployment_sets(self) -> None:
           logger.info(f"Syncing entities for blueprint {BLUEPRINT.DEPLOYMENT_SET}")
           applications = await self.humanitec_client.get_all_applications()

           def create_deployment_set_entity(deployment_set, application):
               return {
                   "identifier": f"{application['id']}/{deployment_set['id']}",
                   "title": self.remove_symbols_and_title_case(deployment_set.get("name", deployment_set["id"])),
                   "properties": {
                       "version": deployment_set.get("version"),
                       "createdAt": deployment_set.get("created_at"),
                       "createdBy": deployment_set.get("created_by"),
                       "comment": deployment_set.get("comment"),
                   },
                   "relations": {BLUEPRINT.APPLICATION: application["id"]},
               }

           tasks = []
           for application in applications:
               deployment_sets = await self.humanitec_client.get_deployment_sets(application)
               tasks.extend([
                   self.port_client.upsert_entity(
                       blueprint_id=BLUEPRINT.DEPLOYMENT_SET,
                       entity_object=create_deployment_set_entity(deployment_set, application),
                   )
                   for deployment_set in deployment_sets
               ])

           await asyncio.gather(*tasks)
           logger.info(f"Finished syncing entities for blueprint {BLUEPRINT.DEPLOYMENT_SET}")

       async def sync_pipelines(self) -> None:
           logger.info(f"Syncing entities for blueprint {BLUEPRINT.PIPELINE}")
           pipelines = await self.humanitec_client.get_pipelines()

           # Get cached applications to map pipeline to app names
           applications = await self.humanitec_client.get_all_applications()
           app_map = {app["id"]: app for app in applications}

           def create_pipeline_entity(pipeline):
               app_id = pipeline.get("app_id")
               app_name = app_map.get(app_id, {}).get("name", "Unknown App")

               # Create identifier that includes app context
               identifier = f"{app_id}/{pipeline['id']}"

               # Create title that includes app name and pipeline name
               pipeline_name = pipeline.get("name", pipeline["id"])
               title = f"{app_name} - {pipeline_name}"

               return {
                   "identifier": identifier,
                   "title": title,
                   "properties": {
                       "etag": pipeline.get("etag"),
                       "name": pipeline.get("name"),
                       "status": pipeline.get("status"),
                       "version": pipeline.get("version"),
                       "createdAt": pipeline.get("created_at"),
                       "triggerTypes": pipeline.get("trigger_types", []),
                       "metadata": pipeline.get("metadata", {}),
                   },
                   "relations": {
                       BLUEPRINT.APPLICATION: app_id
                   } if app_id else {},
               }

           tasks = [
               self.port_client.upsert_entity(
                   blueprint_id=BLUEPRINT.PIPELINE,
                   entity_object=create_pipeline_entity(pipeline),
               )
               for pipeline in pipelines
           ]

           await asyncio.gather(*tasks)
           logger.info(f"Finished syncing entities for blueprint {BLUEPRINT.PIPELINE}")

       async def sync_deployment_deltas(self) -> None:
           logger.info(f"Syncing entities for blueprint {BLUEPRINT.DEPLOYMENT_DELTA}")
           applications = await self.humanitec_client.get_all_applications()

           def create_deployment_delta_entity(deployment_delta, application):
               return {
                   "identifier": f"{application['id']}/{deployment_delta['id']}",
                   "title": self.remove_symbols_and_title_case(deployment_delta.get("name", deployment_delta["id"])),
                   "properties": {
                       "status": deployment_delta.get("status"),
                       "createdAt": deployment_delta.get("created_at"),
                       "createdBy": deployment_delta.get("created_by"),
                       "comment": deployment_delta.get("comment"),
                       "environment": deployment_delta.get("environment"),
                   },
                   "relations": {BLUEPRINT.APPLICATION: application["id"]},
               }

           tasks = []
           for application in applications:
               deployment_deltas = await self.humanitec_client.get_deployment_deltas(application)
               tasks.extend([
                   self.port_client.upsert_entity(
                       blueprint_id=BLUEPRINT.DEPLOYMENT_DELTA,
                       entity_object=create_deployment_delta_entity(deployment_delta, application),
                   )
                   for deployment_delta in deployment_deltas
               ])

           await asyncio.gather(*tasks)
           logger.info(f"Finished syncing entities for blueprint {BLUEPRINT.DEPLOYMENT_DELTA}")

       async def sync_users_and_groups(self) -> None:
           logger.info(f"Syncing entities for blueprints {BLUEPRINT.USER} and {BLUEPRINT.GROUP}")

           all_users, all_groups = await self.humanitec_client.get_users_and_groups()

           user_groups = {}

           for user in all_users:
               user_groups[user["id"]] = []

           group_tasks = [
               self.humanitec_client.get_users_in_group(group["id"])
               for group in all_groups
           ]

           group_results = await asyncio.gather(*group_tasks, return_exceptions=True)

           for i, result in enumerate(group_results):
               group_id = all_groups[i]["id"]

               if isinstance(result, Exception):
                   logger.error(f"Failed to get users for group {group_id}: {str(result)}")
                   continue

               for user in result:
                   user_id = user["id"]
                   if user_id in user_groups:
                       user_groups[user_id].append(group_id)

           def create_group_entity(group):
               return {
                   "identifier": group["id"],
                   "title": group["name"],
                   "properties": {
                       "role": group.get("role"),
                       "idp_id": group.get("idp_id"),
                       "createdAt": group.get("created_at"),
                   },
                   "relations": {},
               }

           def create_user_entity(user):
               return {
                   "identifier": user["id"],
                   "title": user["name"],
                   "properties": {
                       "email": user.get("email"),
                       "role": user.get("role"),
                       "invite": user.get("invite"),
                       "createdAt": user.get("created_at"),
                   },
                   "relations": {
                       BLUEPRINT.GROUP: user_groups.get(user["id"], [])
                   },
               }

           group_tasks = [
               self.port_client.upsert_entity(
                   blueprint_id=BLUEPRINT.GROUP,
                   entity_object=create_group_entity(group),
               )
               for group in all_groups
           ]

           user_tasks = [
               self.port_client.upsert_entity(
                   blueprint_id=BLUEPRINT.USER,
                   entity_object=create_user_entity(user),
               )
               for user in all_users
           ]

           await asyncio.gather(*(group_tasks + user_tasks))
           logger.info(f"Finished syncing {len(all_groups)} groups and {len(all_users)} users")

       async def sync_all(self) -> None:
           await self.sync_applications()
           await self.sync_environments()
           await self.sync_workloads()
           await self.sync_resource_graphs()
           await self.sync_resources()
           await self.sync_secret_stores()
           await self.sync_shared_values()
           await self.sync_value_set_versions()
           await self.sync_deployment_sets()
           await self.sync_pipelines()
           await self.sync_deployment_deltas()
           await self.sync_users_and_groups()
           logger.info("Event Finished")

       async def __call__(self, args) -> None:
           await self.sync_all()


   if __name__ == "__main__":

       def validate_args(args):
           required_keys = ["org_id", "api_key", "port_client_id", "port_client_secret"]
           missing_keys = [key for key in required_keys if not getattr(args, key)]

           if missing_keys:
               logger.error(f"The following keys are required: {', '.join(missing_keys)}")
               return False
           return True

       parser = argparse.ArgumentParser()
       parser.add_argument(
           "--org-id",
           required=False,
           default=config("ORG_ID", ""),
           type=str,
           help="Humanitec organization ID",
       )
       parser.add_argument(
           "--api-key",
           required=False,
           default=config("API_KEY", ""),
           type=str,
           help="Humanitec API key",
       )
       parser.add_argument(
           "--api-url",
           type=str,
           default=config("API_URL", "https://api.humanitec.com"),
           help="Humanitec API URL",
       )
       parser.add_argument(
           "--port-client-id",
           type=str,
           required=False,
           default=config("PORT_CLIENT_ID", ""),
           help="Port client ID",
       )
       parser.add_argument(
           "--port-client-secret",
           type=str,
           required=False,
           default=config("PORT_CLIENT_SECRET", ""),
           help="Port client secret",
       )
       args = parser.parse_args()
       if not (validate_args(args)):
           import sys

           sys.exit()

       exporter = HumanitecExporter(args)
       asyncio.run(exporter(args))


   Requirements (Click to expand)

   requirements.txt


   python-decouple==3.8
   loguru==0.7.2
   httpx==0.27.0
   loguru==0.7.2

2. Create the following Python files in a folder named clients at the base directory of the integration folder:

   • port_client.py – Manages authentication and API requests to Port, facilitating the creation and updating of entities within Port's system.
   • humanitec_client.py – Handles API interactions with Humanitec, including retrieving data with caching mechanisms to optimize performance.
   • cache.py - Provides an in-memory caching mechanism with thread-safe operations for setting, retrieving, and deleting cache entries asynchronously.

Port Client (Click to expand)

port_client.py

import httpx
from typing import Any, Dict
from loguru import logger
from typing import Dict


class PortClient:
    def __init__(self, client_id, client_secret, **kwargs) -> None:
        self.httpx_async_client = kwargs.get("httpx_async_client", httpx.AsyncClient())
        self.client_id = client_id
        self.client_secret = client_secret
        self.base_url = kwargs.get("base_url", "https://api.getport.io/v1")
        self.port_headers = None

    async def get_port_access_token(self) -> str:
        credentials = {"clientId": self.client_id, "clientSecret": self.client_secret}
        endpoint = f"/auth/access_token"
        response = await self.send_api_request("POST", endpoint, json=credentials)
        access_token = response["accessToken"]
        return access_token

    async def get_port_headers(self) -> Dict[str, str]:
        access_token = await self.get_port_access_token()
        port_headers = {"Authorization": f"Bearer {access_token}"}
        return port_headers

    async def send_api_request(
        self,
        method: str,
        endpoint: str,
        headers: Dict[str, str] | None = None,
        json: Dict[str, Any] | None = None,
    ) -> Dict[str, Any]:
        url = f"{self.base_url}{endpoint}"
        try:
            response = await self.httpx_async_client.request(
                method, url, headers=headers, json=json
            )
            response.raise_for_status()
            return response.json()
        except httpx.HTTPStatusError as e:
            logger.error(f"HTTP error occurred: {e.response.text}")
            raise
        except Exception as e:
            logger.error(f"An error occurred: {str(e)}")
            raise

    async def upsert_entity(
        self, blueprint_id: str, entity_object: Dict[str, Any]
    ) -> Dict[str, Any]:
        endpoint = f"/blueprints/{blueprint_id}/entities?upsert=true&merge=true"
        port_headers = (
            self.port_headers if self.port_headers else await self.get_port_headers()
        )
        response = await self.send_api_request(
            "POST", endpoint, headers=port_headers, json=entity_object
        )
        logger.info(response)
        return response

Humanitec Client (Click to expand)

humanitec_client.py

import httpx
import asyncio
from typing import Dict, Any, List
import datetime
import re
from loguru import logger
from .cache import InMemoryCache


class CACHE_KEYS:
    APPLICATION = "APPLICATION_CACHE_KEY"
    ENVIRONMENT = "ENVIRONMENT_CACHE_KEY"
    RESOURCE = "RESOURCE_CACHE_KEY"


class HumanitecClient:
    def __init__(self, org_id, api_token, **kwargs) -> None:
        self.client = kwargs.get("httpx_async_client", httpx.AsyncClient())
        self.base_url = (
            f"{kwargs.get('base_url','https://api.humanitec.io')}/orgs/{org_id}/"
        )
        self.api_token = api_token
        self.cache = InMemoryCache()
        self.port_headers = None

    def get_humanitec_headers(self) -> Dict[str, str]:
        humanitec_headers = {
            "Authorization": f"Bearer {self.api_token}",
            "Content-Type": "application/json",
        }
        return humanitec_headers

    async def send_api_request(
        self,
        method: str,
        endpoint: str,
        headers: Dict[str, str] | None = None,
        json: Dict[str, Any] | List[Dict[str, Any]] | None = None,
    ) -> Any:
        url = self.base_url + endpoint
        try:
            logger.debug(f"Requesting Humanitec data for endpoint: {endpoint}")
            response = await self.client.request(
                method, url, headers=headers, json=json
            )
            response.raise_for_status()
            return response.json()
        except httpx.HTTPStatusError as e:
            logger.error(f"HTTP error occurred: {e.response.text}")
            raise
        except Exception as e:
            logger.error(f"An error occurred: {str(e)}")
            raise

    async def get_all_applications(self) -> List[Dict[str, Any]]:
        if cached_applications := await self.cache.get(CACHE_KEYS.APPLICATION):
            logger.info(f"Retrieved {len(cached_applications)} applications from cache")
            return list(cached_applications.values())

        endpoint = "apps"
        humanitec_headers = self.get_humanitec_headers()
        applications: List[Dict[str, Any]] = await self.send_api_request(
            "GET", endpoint, headers=humanitec_headers
        )

        await self.cache.set(
            CACHE_KEYS.APPLICATION, {app["id"]: app for app in applications}
        )
        logger.info(f"Received {len(applications)} applications from Humanitec")

        return applications

    async def get_all_environments(self, app) -> List[Dict[str, Any]]:

        try:
            if cached_environments := await self.cache.get(CACHE_KEYS.ENVIRONMENT):
                if app_environments := cached_environments.get(app["id"]):
                    logger.info(
                        f"Retrieved {len(app_environments)} environment for {app['id']} from cache"
                    )
                    return list(app_environments.values())

            logger.info("Fetching environments from Humanitec")

            endpoint = f"apps/{app['id']}/envs"
            humanitec_headers = self.get_humanitec_headers()
            environments: List[Dict[str, Any]] = await self.send_api_request(
                "GET", endpoint, headers=humanitec_headers
            )
            await self.cache.set(
                CACHE_KEYS.ENVIRONMENT,
                {
                    app["id"]: {
                        environment["id"]: environment for environment in environments
                    }
                },
            )
            logger.info(f"Received {len(environments)} environments from Humanitec")
            return environments
        except Exception as e:
            logger.error(f"Failed to fetch environments from {app['id']}: {str(e)}")
            return []

    async def get_all_resources(self, app, env) -> List[Dict[str, Any]]:
        try:
            if cached_resources := await self.cache.get(CACHE_KEYS.RESOURCE):
                if env_resources := cached_resources.get(app["id"], {}).get(
                    env["id"]
                ):
                    logger.info(
                        f"Retrieved {len(env_resources)} resources from cache for app {app['id']} and env {env['id']}"
                    )
                    return list(env_resources.values())

            logger.info("Fetching resources from Humanitec")
            endpoint = f"apps/{app['id']}/envs/{env['id']}/resources"
            humanitec_headers = self.get_humanitec_headers()
            resources: List[Dict[str, Any]] = await self.send_api_request(
                "GET", endpoint, headers=humanitec_headers
            )
            await self.cache.set(
                CACHE_KEYS.RESOURCE,
                {
                    app["id"]: {
                        env["id"]: {
                            resource["gu_res_id"]: resource for resource in resources
                        }
                    }
                },
            )
            logger.info(
                f"Received {len(resources)} resources for {env['id']} environment in {app['id']}"
            )
            return resources
        except Exception as e:
            logger.error(
                f"Failed to fetch resources for {env['id']} environment in {app[id]}: {str(e)}"
            )
            return []

    async def get_dependency_graph(
        self, app: Dict[str, Any], env: Dict[str, Any]
    ) -> List[Dict[str, Any]]:
        try:
            if dependency_graph_id := env.get("last_deploy", {}).get("dependency_graph_id"):
                endpoint = f"apps/{app['id']}/envs/{env['id']}/resources/graphs/{dependency_graph_id}"
                humanitec_headers = self.get_humanitec_headers()
                graph = await self.send_api_request(
                    "GET", endpoint, headers=humanitec_headers
                )
                nodes = graph["nodes"]
                logger.info(
                    f"Received {len(nodes)} graph nodes for {env['id']} environment in {app['id']}"
                )
                return nodes

            logger.info(
                f"No dependency graph found for {env['id']} environment in {app['id']}"
            )
            return []
        except Exception as e:
            logger.error(
                f"Failed to fetch dependency graphs for {env['id']} environment in {app['id']}: {str(e)}"
            )
            return []

    async def get_resource_graph(
        self, app: Dict[str, Any], env: Dict[str, Any], data: List[Dict[str, Any]]
    ) -> Any:
        endpoint = f"apps/{app['id']}/envs/{env['id']}/resources/graph"
        humanitec_headers = self.get_humanitec_headers()
        graph = await self.send_api_request(
            "POST", endpoint, headers=humanitec_headers, json=data
        )
        return graph

    def group_resources_by_type(
        self, data: List[Dict[str, Any]]
    ) -> Dict[str, List[Dict[str, Any]]]:
        grouped_resources: dict[str, Any] = {}
        for resource in data:
            workload_id = resource["res_id"].split(".")[0]
            if workload_id not in grouped_resources:
                grouped_resources[workload_id] = []
            grouped_resources[workload_id].append(resource)
        return grouped_resources

    async def get_secret_stores(self) -> List[Dict[str, Any]]:
        """Get all secret stores for the organization."""
        endpoint = "secretstores"
        humanitec_headers = self.get_humanitec_headers()
        secret_stores: List[Dict[str, Any]] = await self.send_api_request(
            "GET", endpoint, headers=humanitec_headers
        )
        logger.info(f"Received {len(secret_stores)} secret stores from Humanitec")
        return secret_stores

    async def get_shared_values(self, app: Dict[str, Any], env: Dict[str, Any]) -> List[Dict[str, Any]]:
        """Get shared values for a specific environment."""
        endpoint = f"apps/{app['id']}/envs/{env['id']}/values"
        humanitec_headers = self.get_humanitec_headers()
        shared_values: List[Dict[str, Any]] = await self.send_api_request(
            "GET", endpoint, headers=humanitec_headers
        )
        logger.info(f"Received {len(shared_values)} shared values for {env['id']} environment in {app['id']}")
        return shared_values

    async def get_shared_values_app_level(self, app: Dict[str, Any]) -> List[Dict[str, Any]]:
        """Get shared values at application level."""
        endpoint = f"apps/{app['id']}/values"
        humanitec_headers = self.get_humanitec_headers()
        shared_values: List[Dict[str, Any]] = await self.send_api_request(
            "GET", endpoint, headers=humanitec_headers
        )
        logger.info(f"Received {len(shared_values)} app-level shared values for {app['id']}")
        return shared_values

    async def get_value_set_versions(self, app: Dict[str, Any]) -> List[Dict[str, Any]]:
        """Get value set versions for an application."""
        endpoint = f"apps/{app['id']}/value-set-versions"
        humanitec_headers = self.get_humanitec_headers()
        value_set_versions: List[Dict[str, Any]] = await self.send_api_request(
            "GET", endpoint, headers=humanitec_headers
        )
        logger.info(f"Received {len(value_set_versions)} value set versions for {app['id']}")
        return value_set_versions

    async def get_deployment_sets(self, app: Dict[str, Any]) -> List[Dict[str, Any]]:
        """Get deployment sets for an application."""
        endpoint = f"apps/{app['id']}/sets"
        humanitec_headers = self.get_humanitec_headers()
        deployment_sets: List[Dict[str, Any]] = await self.send_api_request(
            "GET", endpoint, headers=humanitec_headers
        )
        logger.info(f"Received {len(deployment_sets)} deployment sets for {app['id']}")
        return deployment_sets

    async def get_pipelines(self) -> List[Dict[str, Any]]:
        """Get all pipelines in the organization."""
        endpoint = "pipelines"
        humanitec_headers = self.get_humanitec_headers()
        pipelines: List[Dict[str, Any]] = await self.send_api_request(
            "GET", endpoint, headers=humanitec_headers
        )
        logger.info(f"Received {len(pipelines)} pipelines from Humanitec")
        return pipelines

    async def get_deployment_deltas(self, app: Dict[str, Any]) -> List[Dict[str, Any]]:
        """Get deployment deltas for an application."""
        endpoint = f"apps/{app['id']}/deltas"
        humanitec_headers = self.get_humanitec_headers()
        deployment_deltas: List[Dict[str, Any]] = await self.send_api_request(
            "GET", endpoint, headers=humanitec_headers
        )
        logger.info(f"Received {len(deployment_deltas)} deployment deltas for {app['id']}")
        return deployment_deltas

    async def get_users_and_groups(self) -> tuple[List[Dict[str, Any]], List[Dict[str, Any]]]:
        """Get all users and groups in the organization from a single API call."""
        endpoint = "users"
        humanitec_headers = self.get_humanitec_headers()
        all_entities: List[Dict[str, Any]] = await self.send_api_request(
            "GET", endpoint, headers=humanitec_headers
        )

        users = []
        groups = []
        for entity in all_entities:
            if entity.get("type") == "user":
                users.append(entity)
            elif entity.get("type") == "group":
                groups.append(entity)

        logger.info(f"Received {len(users)} users and {len(groups)} groups from Humanitec")
        return users, groups

    async def get_users_in_group(self, group_id: str) -> List[Dict[str, Any]]:
        """Get all users in a specific group."""
        endpoint = f"groups/{group_id}/users"
        humanitec_headers = self.get_humanitec_headers()
        users: List[Dict[str, Any]] = await self.send_api_request(
            "GET", endpoint, headers=humanitec_headers
        )
        logger.info(f"Received {len(users)} users in group {group_id}")
        return users

Cache (Click to expand)

cache.py

import asyncio
from typing import Dict, Any

class InMemoryCache:
    def __init__(self):
        self.cache = {}
        self.lock = asyncio.Lock()

    async def set(self, key, data):
        """
        Sets or updates a cache entry with the given key.

        Parameters:
        - key (str): The key to use for the cache entry.
        - data (dict): The data to be cached.
        """
        async with self.lock:
            if key in self.cache:
                self.cache[key].update(data)
            else:
                self.cache[key] = data
            return True

    async def get(self, key) -> Dict[str, Any]:
        """
        Retrieves cached data using the given key.

        Parameters:
        - key (str): The key to retrieve from the cache.

        Returns:
        - dict: The cached data associated with the key, or None if not found.
        """
        async with self.lock:
            return self.cache.get(key, {})

    async def delete(self, key):
        """
        Deletes cached data associated with the given key.

        Parameters:
        - key (str): The key to delete from the cache.

        Returns:
        - bool: True if deletion was successful, False otherwise (key not found).
        """
        async with self.lock:
            if key in self.cache:
                del self.cache[key]
                return True
            return False

Create the GitHub workflow

Create the file .github/workflows/humanitec-exporter.yaml in the .github/workflows folder of your repository.

Cron

Adjust the cron expression to fit your schedule. By default, the workflow is set to run at 2:00 AM every Monday ('0 2 * * 1').

GitHub Workflow (Click to expand)

humanitec-exporter.yaml

name: Ingest Humanitec Integration Resources

on:
  schedule:
    - cron: '0 2 * * 1'
  workflow_dispatch:

jobs:
  ingest-humanitec-resources:
    runs-on: ubuntu-latest
    steps:
      - name: Checkout code
        uses: actions/checkout@v4

      - name: Set up Python
        uses: actions/setup-python@v5
        with:
          python-version: '3.x'

      - name: Install Python dependencies
        run: |
          python -m pip install --upgrade pip
          pip install -r requirements.txt

      - name: Ingest Entities to Port
        env:
            PORT_CLIENT_ID: ${{ secrets.PORT_CLIENT_ID }}
            PORT_CLIENT_SECRET: ${{ secrets.PORT_CLIENT_SECRET }}
            API_KEY: ${{ secrets.HUMANITEC_API_KEY }}
            ORG_ID: ${{secrets.HUMANITEC_ORG_ID }}
        run: |
          python integration/main.py

Done! Any change that happens to your application, environment, workloads, resources, resource graphs, pipelines, deployment deltas, deployment sets, secret stores, shared values, value set versions, users, groups in Humanitec will be synced to Port on the schedule interval defined in the GitHub workflow.
